    YX-800/1000 Building Material Glazing Roof Tile Roll Fomring Making Machine

    Ask Lasest Price
    Brand Name : CHBEST
    Model Number : YX-800/1000
    Certification : CE,BV,SGS
    Price : USD8500-25500/set
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 20sets/month
    Delivery Time : 5-60days
    • Product Details
    • Company Profile

    YX-800/1000 Building Material Glazing Roof Tile Roll Fomring Making Machine

    YX-800/1000 Building Material Glazing Roof Tile Roll Fomring Making Machine

    1. Working Flow:

    Decoiler--feeding materil--roll formng--pressing and cutting--output table


    2. Component:

    COMPONENT FOR Roof Sheet Glazed Tiles Roll Forming Machine
    Name
    Quantity
    Units
    Decoiler
    1
    Set
    Main Machine
    Feeding device
    1
    Set
    Roll forming system
    1
    Set
    Cut Equipment
    1
    Set
    Hydraulic system
    1
    Set
    Electric control system
    1
    Set
    Supporter/Automatic Stacker
    1
    Set

    3. Parameter

    Article No.Item NameSpecification
    1Width of feeding material1000mm,1200mm coil sheet
    2Thickness of feeding material0.3-0.8mm coil sheet
    3Roller station13 stations
    4Shaft Diameter75mm
    5Productivity3-5m/min
    6Rollers' material45# steel with 0.05mm chrome
    7Shaft material45# steel with 0.05mm chrome
    8Weight6.5 ton
    9length6.5 m
    10Voltage380V 50Hz 3phases
    11ControlPLC
    12Decoiler8 Tons
    13Motor5.5 kw
    14Driving wayChain transmission
    15Chain size1 inch
    16Cutting systemHydraulic cutter

    4. Our service:

    1. Installation and training:

    A. If buyers visit our factory and check the machine, we will teach you how to install and use the machine,

    and also trainyour workers/technician face to face.

    B. Without visiting, we will send you user manual and video to teach you to install and operate.

    C. If buyer needs our technician to go to your local factory, please arrange board and lodging and

    other necessary things.

    2. after Service
    A. One year guarantee for whole machine.
    B. 24 hours technical support by email or phone call.
    C. If there is any problem found of the machine, we will repair it for free in one year.


    FAQ:

    1. Can you be responsible for transport?

    Yes, please tell me the destination port or address.we have rich experience in transport.

    2. You are Trade Company or factory?

    We are trade company but we also have own factories. Building Trade Company is just for exporting various types of cold roll forming machines.

    3. How long the machine could be made?

    Normally speaking, welded pipe making machine could be made without 45 working days. If you need machines in a hurry, we can make it for you less than a month.


    If you are interested in our machine, please contact me to get more details...

    5. Machine photos:


    Application:


    6. Our customer:
