    Automatic IBR Roofing Sheet Roll Forming Machine 5.5kw Main Power

    Ask Lasest Price
    Brand Name : CHBEST
    Model Number : XY1050
    Certification : CE/BV/SGS
    Supply Ability : 20 sets/month
    Delivery Time : 20-30 days
    • Product Details
    • Company Profile

    Automatic IBR Roofing Sheet Roll Forming Machine 5.5kw Main Power

    Automatic IBR Roofing Sheet Roll Forming Machine 5.5kw Main Power

    Working flow:

    Uncoiler -Feeding -Straightening-Roll Forming -Cutting-Exit Rack


    Main Specifications:


    Thickness of coil sheet

    0.3-0.8MM,GI/PPGI

    Under frame

    400H-beam

    Diameter of Soild shaft

    80mm, high grade 45# steel,with keyway

    Roller

    High grade Gcr15, processed by CNC lathe,

    hard chromed 0.05-0.07mm

    Thickness of middle plate

    20mm

    Forming stations

    18

    Drive type

    By chain(1.2 inch) link bearing model 6210

    Power of main motor

    11kw with Cycloidal reducer, Lichao, Shanghai

    Power of pump station

    5.5kw, Lichao, Shanghai

    Forming speed

    About 15-20m/min

    Blanking cutting

    (3 pieces of blade)

    Controlled by PLC

    PLC

    DELTA, TAIWAN / Mitsubishi, Japan

    Material of cutting blade

    Cr12Mov, quenching 58-62℃

    Punching Device

    2 sets

    Machine Component

    Name

    Quantity

    Units

    Decoiler

    1

    Set

    Main Machine

    Feeding device

    1

    Set

    Roll forming system

    1

    Set

    Cut Equipment

    1

    Set

    Hydraulic system

    1

    Set

    Electric control system

    1

    Set

    Supporter/Automatic Stacker

    1

    Set


    Working conditions
    1.working size25m x 2m x 4m
    2.Power supply8.5kw
    3.Frequency50-60HZ
    4.Wires/cables4-6mm²(length according to workshop)
    5. Labor cost2 workers
    6. ToolsSpanners and screwdriver
    7.Lift device3-5t forklift or crane

    Our Service:


    - Provide Pre-sales Consultant & On-purchase service 8 hr × 6 days per week

    - Reply within 24 hours

    - Provide relevant product information

    - Answer questions if request

    - Give technical suggestion

    Provide After-sales service 24hr × 7days per week

    - Test the machine before shipment

    - Provide technical guidance relate to use the machine

    - Supply one-year warranty period for the machine

    - Provide the spare parts at cost price after warranty period

    - Collect the feedback for the machine working

    - Provide long-term technical assistance.


    Why choose us?
    1.We can make and design all kinds of roll forming machine according to customer's requests.
    2.This is a very perfect and durable equipment. We have more than 13 years experiences.
    3.This kind of machine has the best quality and the best price. It has accurate measurement and easy operating.
    4.We can design and manufacture the special type machine according to the customers' requirement and we could provide technical guiding, production, installation, debugging and maintenance service to all customers.
    5. Our product has been exported to many regions and won high reputation because of the high quality and reasonable price.


    Machine Photo
