    Price Sheet for Galvanized Steel Profile Metal Roofing Making Sheeting Corrugated Roof Sheet Machine

    Ask Lasest Price
    Brand Name : BEST
    Certification : CE
    Price : USD6000--10000
    Payment Terms : L/C, T/T
    Supply Ability : 20 sets/month
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Price Sheet for Galvanized Steel Profile Metal Roofing Making Sheeting Corrugated Roof Sheet Machine

    Price Sheet for Galvanized Steel Profile Metal Roofing Making Sheeting Corrugated Roof Sheet Machine

    SALIENT FEATURES

    Technological Process of IBR Roof Sheet Roll Forming Machine

    Decoiler — feeding — guide --- roll forming ---- cut to length — run out table

    Description of IBR Roof Sheet Roll Forming Machine

    • We have professional engineering team and can use the Copra Software skillfully to design the forming diagram according to the profile drawing.
    • We adopt the heavy stands to make the machine robust and strong.
    • We adopt pneumatic saw flying cut to shear all profiles
    • The step beams is popularly used in the project of supermarket construction in North America and
    • South America e.g Mexico, Argentina, Chile and so on
    • We exported the step beam machine to Mexico and all of the profiles produced can meet the customer's requirements
    • We also can supply accessories parts machine together with rack machine, crossbar machine, base machine etc

    Composition of IBR Roof Sheet Roll Forming Machine

    Manual Un coiler1 unit
    Control panel1 unit
    Roll forming main machine1 unit
    Cutting Device1 unit
    Manual out table2 unit

    Equipment List :

    • De-coiler (Manual)
    • Main roll forming machine (24 stand)
    • Hydraulic post cutoff unit
    • Hydraulic power pack
    • Back cutter
    • Lamination unit
    • Electrical control system


    De-Coiler :

    • Weight of the machine : 2500 kg
    • Capacity : 5000 kg max
    • Coil id : 510 mm
    • Max coil width can be loaded : 1450mm
    • Min coil width can be loaded :- 500 mm


    Electrical Control System :

    • Destined for electrical controlling of line equipment
    • Fabricated sheet metal enclosure
    • Easy accessibly mounting of components
    • PLC control mechanism system for high accuracy in length control.
    • Front panel with operator interface, push button panel, operating & indicators.
    • For ease of operation operator pendent can be at difference desired place on line.
    • Mains with 3 phase 4 wire necessary protections shall be arranged by us near main panel console.
    • HMI 3x3 Touch color screen
    • Variable frequency Drive
    • Encoder
    • Contactor,relay,smps,
    • Auto single plece system
    • auto machine length counting


    Terms & Condition :

    • 50% Advance Payment , Full Payment after trial at our workshop.
    • Free training your operator person.
    • One year service ( Ticket & Accommodation in your scope)
    • GST extra.
    • Ex Factory Rate
    • Erection Charges will be Extra
    • Transportation Extra as actual

    Reference IBR Roof Sheet Drawing

    IBR Roof Sheet Roll Forming Machine1

    Production Line Sketch
    IBR Roof Sheet Roll Forming Machine2

    Applications
    IBR Roofing Sheet; IBR Sheet; IBR Roofing Sheet; Metal roof; Steel roof; Metal roof wall panel; Steel roof wall panel; Metal roofing sheet; Steel roofing sheet; Metal roof panel; Steel roof panel; Beams; C beams;
    Step beams in the supermarket

    Competitive Advantage
    One roll forming machine only can produce one profile.
    We can manufacture as per customer provided drawings with the specification or real objects of sectional materials,
    custom roll forming machine is welcome.

    More information about steel roof panel profiles, Pls contact with us!

    TECHNICAL PARAMETERS

    Specifications of IBR Roof Sheet Roll Forming Machine

    No.ItemDescription
    1.Coil widthDepend on your profiles
    2.Working speed12-15m/min
    3.Roll stationabout 16 - 24 stations
    4.Material of rollerGrade 45 steel, polished and
    coated with chrome
    5.Material of main shaft45﹟ steel
    6Diameter roller70mm
    7.Main power7.5KW
    8.Forming thickness1.0mm zinc and color steel, 250Mpa-G550MPA
    9.Transmissionby single Chains 1.5inch
    10.Feeding and guideSurface polished and coated with chrome
    11.Machine drive partsAdopt protect cover
    12.Machine stationAdopt new station with chrome
    13.Size of main machine7500x1500x1300(mm)
    L x W x H need 1x40GP container
    14.Weightabout 8000Kgs
    15.Color of machineBlue ( or depend on customer's request)
    16.Machine legsFour legs (made from metal) in 350mm
    Machine Specs
    Suitable for rollingpre-painted galvanized steel 0.3~0.8mm thick
    Cycle Time15m/min
    Cut-off System4kW Hydraulic Cutting
    Power19.5kW
    Dimensions
    Machine Size11 000 x 1 900 x 1 600mm
    Forming Stations22 stations

    machine picture
